Product Description

Ecoplus systems have worked closely with the AUAS to develop an innovative range of ceiling tiles with extremely high levels of Class A sound absorption.

The Acoustic Plus Sound Absorber ceiling tile (1200mmx60mm) in 15mm, 25mm, or 50mm  thick provide a high level of sound absorption & control of background noise levels. They have been tested and measured by Auckland University Acoustic Services.

The Dual bloc 35 is a composition of the Acoustic plus 25mm with a 9mm sheet of plasterboard attached to the top service whist the DB 60 is the 50mm Acoustic Plus tile with the plasterboard.

Coming in a matte white finish, Ecoplus systems is proud to claim benefits such as rigid and self supporting panels with anti sag enclosed edges, demountable and easily cleanable and resistant to mould and bacteria.







Technical and Environmental Benefits

These ceiling tiles provide acoustic benefit, reducing background noise and reverberation, and having an NRC value of 0.85 for 15mm,  0.90 for 25mm, and 0.95 for the 50mm tiles, as verified by Auckland University acoustic testing.

Thermal Resistance values as tested are up to R 0.8 m2 K/W for 25mm tile.

These ceiling  tiles are light weight being 1.5kg /m2 for 15mm tile and 2.5kg/m2 for 25mm tile, and have a Fire Class rating of NZBC Group 1S as appraised by BRANZ.



Manufacturer Information - China Top Building Materials Corporation

China Top Building Materials International Corporation(GROUP) is a professional manufacturer for interior decoration materials in China, located in Beijing, the capital of China. with a total area of 100000 square meters land coverage, equipped with more than 36 production lines, achieved a total yearly productivity of more than 7000000M2 Acoustic ceiling panel tiles.



Supplier Information - Ecoplus Systems

Ecoplus Systems supply innovative and performance tested suspended ceiling systems, acoustic ceiling solutions and decorative wall treatments.

Their products are installed into a wide range of applications including offices, restaurants and hospitality, call centres, supermarkets, gyms, schools, libraries and medical facilities. We supply throughout New Zealand.

Application and Purpose

Both Acoustic Plus Sound Absorber ceiling tiles are ideal for large format retail spaces, Schools/educational facilities, open plan offices and call centres, and any area requiring a good level of acoustic efficiency.



Installation and Maintenance

These ceiling tiles are suitable for installation by an appropriately qualified trade contractor.

Acoustic Plus ceiling tiles can be easily maintained by cleaning with a soft nozzle vacuum, soft brush, or damp cloth.
